| Correias e Polias Sincronizadoras |
| PERFIS |
| PASSO |
DISTANCIA(mm) |
DENTE |
| 3M |
3,0 |
SEMI CIRCULAR |
| 5M |
5,0 |
SEMI CIRCULAR |
| 8M |
8,0 |
SEMI CIRCULAR |
| 14M |
14,0 |
SEMI CIRCULAR |
| 20M |
20,0 |
SEMI CIRCULAR |
| |
|
|
| MXL |
2,032 (0,800”) |
TRAPEZOIDAL |
| XL |
5,08 (1/5”) |
TRAPEZOIDAL |
| L |
9,525 (3/8”) |
TRAPEZOIDAL |
| H |
12,7 (1/2”) |
TRAPEZOIDAL |
| XH |
22,225 (7/8”) |
TRAPEZOIDAL |
| XXH |
31,75 (1 ¼”) |
TRAPEZOIDAL |
| |
|
|
| T 2,5 |
2,5 |
TRAPEZOIDAL |
| T 5/AT |
55,0 |
TRAPEZOIDAL |
| T10/AT 10 |
10,0 |
TRAPEZOIDAL |
| T20/AT 20 |
20,0 |
TRAPEZOIDAL |
| |
| S2M – S3M – S4,5M – S5M – S8M – S14M |
|
